Input voltage：AC 100~240V, 50/60Hz

Power consumption：1300W

Light source：608pcs 1W R LED + 608pcs 1W G LED + 608pcs 1W B LED + 608pcs 1W CW LED + 1216pcs 1W CW/WW LED

Color temperature ：2700~10000K±100K

Field angle：110°

optics：CRI: ≥97

CQS: ≥96

TLCI: ≥98

Control mode：

Channel mode：

1.CCT & RGBCW(8bit/11CH)(16bit/20CH),

2.CCT & HSI(8bit/8CH)(16bit/14CH),

3.CCT(8bit/6CH)(16bit/8CH),

4.HSI(8bit/5CH)(16bit/8CH),

5.RGBCW(8bit/8CH)(16bit/14CH),

6.XY(8bit/5CH)(16bit/8CH),

7.RGBCW 8bit 11CH

Remote channel mode: 1.ULTIMATE DMX 8bit - CCT MODE

2.ULTIMATE DMX 8bit - HSI MODE

3.ULTIMATE DMX 8bit - RGBW MODE

4.ULTIMATE DMX 8bit - XY MODE

5.ULTIMATE DMX 8bit - GEL MODE

6.ULTIMATE DMX 8bit - EFFECT MODE

Control protocol：DMX512，RDM，wireless DMX, WIFI-DMX

Software upgrade：BY DMX

Structure：

Display：LCD

Dmx in/out：3pin XLR (optional 5pin XLR)

Power connection：true one in/out

IP rate：IP65

Dimension： 880*182*475mm

Weight: 29.5kgs
